new conference paper “Who Knocks at the IPv6 Door? Detecting IPv6 Scanning” at ACM IMC 2018

We have published a new paper “Who Knocks at the IPv6 Door? Detecting IPv6 Scanning” by Kensuke Fukuda and John Heidemann, in the ACM Internet Measurements Conference (IMC 2018) in Boston, Mass., USA.

DNS backscatter from IPv4 and IPv6 ([Fukuda18a], figure 1).

From the abstract:

DNS backscatter detects internet-wide activity by looking for common reverse DNS lookups at authoritative DNS servers that are high in the DNS hierarchy. Both DNS backscatter and monitoring unused address space (darknets or network telescopes) can detect scanning in IPv4, but with IPv6’s vastly larger address space, darknets become much less effective. This paper shows how to adapt DNS backscatter to IPv6. IPv6 requires new classification rules, but these reveal large network services, from cloud providers and CDNs to specific services such as NTP and mail. DNS backscatter also identifies router interfaces suggesting traceroute-based topology studies. We identify 16 scanners per week from DNS backscatter using observations from the B-root DNS server, with confirmation from backbone traffic observations or blacklists. After eliminating benign services, we classify another 95 originators in DNS backscatter as potential abuse. Our work also confirms that IPv6 appears to be less carefully monitored than IPv4.

Posted in Uncategorized | Tagged , , , , , , , , , , , , , | Leave a comment

new technical report “Plumb: Efficient Processing of Multi-Users Pipelines (Extended)”

We released a new technical report “Plumb: Efficient Processing of Multi-Users Pipelines (Extended)”, by Abdul Qadeer and John Heidemann, as ISI-TR-727.  It is available at

Benefits of processing de-duplication

Benefits of data de-duplication

From the abstract:

Services such as DNS and websites often produce streams of data that are consumed by analytics pipelines operated by multiple teams. Often this data is processed in large chunks (megabytes) to allow analysis of a block of time or to amortize costs. Such pipelines pose two problems: first, duplication of computation and storage may occur when parts of the pipeline are operated by different groups. Second, processing can be lumpy, with structural lumpiness occurring when different stages need different amounts of resources, and data lumpiness occurring when a block of  input requires increased resources. Duplication and structural lumpiness both can result in inefficient processing. Data lumpiness can cause pipeline failure or deadlock, for example if differences in DDoS traffic compared to normal can require 6× CPU. We propose Plumb, a framework to abstract file processing for a multi-stage pipeline. Plumb integrates pipelines contributed by multiple users, detecting and eliminating duplication of computation and intermediate storage. It tracks and adjusts computation of each stage, accommodating both structural and data lumpiness. We exercise Plumb with the processing pipeline for B-Root DNS traffic, where it will replace a hand-tuned system to provide one third the original latency by utilizing 22% fewer CPU and will address limitations that occur as multiple users process data and when DDoS traffic causes huge shifts in performance.


Posted in Uncategorized | Tagged , , , , , , | Leave a comment

congratulations to Liang Zhu for his new PhD

I would like to congratulate Dr. Liang Zhu for defending his PhD in August 2018 and completing his doctoral dissertation “Balancing Security and Performance of Network Request-Response Protocols” in September 2018.

Liang Zhu (left) and John Heidemann, after Liang’s PhD defense.

From the abstract:

The The Internet has become a popular tool to acquire information and knowledge. Usually information retrieval on the Internet depends on request-response protocols, where clients and servers exchange data. Despite of their wide use, request-response protocols bring challenges for security and privacy. For example, source-address spoofing enables denial-of-service (DoS) attacks, and eavesdropping of unencrypted data leaks sensitive information in request-response protocols. There is often a trade-off between security and performance in request-response protocols. More advanced protocols, such as Transport Layer Security (TLS), are proposed to solve these problems of source spoofing and eavesdropping. However, developers often avoid adopting those advanced protocols, due to performance costs such as client latency and server memory requirement. We need to understand the trade-off between security and performance for request-response protocols and find a reasonable balance, instead of blindly prioritizing one of them.
This thesis of this dissertation states that it is possible to improve security of network request-response protocols without compromising performance, by protocol and deployment optimizations, that are demonstrated through measurements of protocol developments and deployments. We support the thesis statement through three specific studies, each of which uses measurements and experiments to evaluate the development and optimization of a request-response protocol. We show that security benefits can be achieved with modest performance costs. In the first study, we measure the latency of OCSP in TLS connections. We show that OCSP has low latency due to its wide use of CDN and caching, while identifying certificate revocation to secure TLS. In the second study, we propose to use TCP and TLS for DNS to solve a range of fundamental problems in DNS security and privacy. We show that DNS over TCP and TLS can achieve favorable performance with selective optimization. In the third study, we build a configurable, general-purpose DNS trace replay system that emulates global DNS hierarchy in a testbed and enables DNS experiments at scale efficiently. We use this system to further prove the reasonable performance of DNS over TCP and TLS at scale in the real world.

In addition to supporting our thesis, our studies have their own research contributions. Specifically, In the first work, we conducted new measurements of OCSP by examining network traffic of OCSP and showed a significant improvement of OCSP latency: a median latency of only 20ms, much less than the 291ms observed in prior work. We showed that CDN serves 94% of the OCSP traffic and OCSP use is ubiquitous. In the second work, we selected necessary protocol and implementation optimizations for DNS over TCP/TLS, and suggested how to run a production TCP/TLS DNS server [RFC7858]. We suggested appropriate connection timeouts for DNS operations: 20s at authoritative servers and 60s elsewhere. We showed that the cost of DNS over TCP/TLS can be modest. Our trace analysis showed that connection reuse can be frequent (60%-95% for stub and recursive resolvers). We showed that server memory is manageable (additional 3.6GB for a recursive server), and latency of connection-oriented DNS is acceptable (9%-22% slower than UDP). In the third work, we showed how to build a DNS experimentation framework that can scale to emulate a large DNS hierarchy and replay large traces. We used this experimentation framework to explore how traffic volume changes (increasing by 31%) when all DNS queries employ DNSSEC. Our DNS experimentation framework can benefit other studies on DNS performance evaluations.


Posted in Uncategorized | Tagged , , , , , , , , , , , , , , , , , | Leave a comment

new conference paper “LDplayer: DNS Experimentation at Scale” at ACM IMC 2018

We have published a new paper LDplayer: DNS Experimentation at Scale by Liang Zhu and John Heidemann, in the ACM Internet Measurements Conference (IMC 2018) in Boston, Mass., USA.

Figure 14a: Evaluation of server memory with different TCP timeouts and minimal RTT (<1 ms). Trace: B-Root-17a. Protocol: TLS

From the abstract:

DNS has evolved over the last 20 years, improving in security and privacy and broadening the kinds of applications it supports. However, this evolution has been slowed by the large installed base and the wide range of implementations. The impact of changes is difficult to model due to complex interactions between DNS optimizations, caching, and distributed operation. We suggest that experimentation at scale is needed to evaluate changes and facilitate DNS evolution. This paper presents LDplayer, a configurable, general-purpose DNS experimental framework that enables DNS experiments to scale in several dimensions: many zones, multiple levels of DNS hierarchy, high query rates, and diverse query sources. LDplayer provides high fidelity experiments while meeting these requirements through its distributed DNS query replay system, methods to rebuild the relevant DNS hierarchy from traces, and efficient emulation of this hierarchy on minimal hardware. We show that a single DNS server can correctly emulate multiple independent levels of the DNS hierarchy while providing correct responses as if they were independent. We validate that our system can replay a DNS root traffic with tiny error (± 8 ms quartiles in query timing and ± 0.1% difference in query rate). We show that our system can replay queries at 87k queries/s while using only one CPU, more than twice of a normal DNS Root traffic rate. LDplayer’s trace replay has the unique ability to evaluate important design questions with confidence that we capture the interplay of caching, timeouts, and resource constraints. As an example, we demonstrate the memory requirements of a DNS root server with all traffic running over TCP and TLS, and identify performance discontinuities in latency as a function of client RTT.

Posted in Uncategorized | Tagged , , , , , , , , , , | Leave a comment

new conference paper “When the Dike Breaks: Dissecting DNS Defenses During DDoS” at ACM IMC 2018

We have published a new paper “When the Dike Breaks: Dissecting DNS Defenses During DDoS” in the ACM Internet Measurements Conference (IMC 2018) in Boston, Mass., USA.

From the abstract:

Caching and retries protect half of clients even with 90% loss and an attack twice the cache duration. (Figure 7c from [Moura18b].)

The Internet’s Domain Name System (DNS) is a frequent target of Distributed Denial-of-Service (DDoS) attacks, but such attacks have had very different outcomes—some attacks have disabled major public websites, while the external effects of other attacks have been minimal. While on one hand the DNS protocol is relatively simple, the \emph{system} has many moving parts, with multiple levels of caching and retries and replicated servers. This paper uses controlled experiments to examine how these mechanisms affect DNS resilience and latency, exploring both the client side’s DNS \emph{user experience}, and server-side traffic. We find that, for about 30\% of clients, caching is not effective. However, when caches are full they allow about half of clients to ride out server outages that last less than cache lifetimes, Caching and retries together allow up to half of the clients to tolerate DDoS attacks longer than cache lifetimes, with 90\% query loss, and almost all clients to tolerate attacks resulting in 50\% packet loss. While clients may get service during an attack, tail-latency increases for clients. For servers, retries during DDoS attacks increase normal traffic up to $8\times$. Our findings about caching and retries help explain why users see service outages from some real-world DDoS events, but minimal visible effects from others.

Datasets from this paper are available at no cost and are listed at


Posted in Uncategorized | Tagged , , , , , , , , , , , , , , , , | Leave a comment

new workshop paper “Leveraging Controlled Information Sharing for Botnet Activity Detection”

We have published a new paper “Leveraging Controlled Information Sharing for Botnet Activity Detection” in the Workshop on Traffic Measurements for Cybersecurity (WTMC 2018) in Budapest, Hungary, co-located with ACM SIGCOMM 2018.

The sensitivity of BotDigger’s detection is im- proved with controlled data sharing. All three domain/IP sets meet or pass the detection threshold.

From the abstract of our paper:

Today’s malware often relies on DNS to enable communication with command-and-control (C&C). As defenses that block traffic improve, malware use sophisticated techniques to hide this traffic, including “fast flux” names and Domain-Generation Algorithms (DGAs). Detecting this kind of activity requires analysis of DNS queries in network traffic, yet these signals are sparse. As bot countermeasures grow in sophistication, detecting these signals increasingly requires the synthesis of information from multiple sites. Yet *sharing security information across organizational boundaries* to date has been infrequent and ad hoc because of unknown risks and uncertain benefits. In this paper, we take steps towards formalizing cross-site information sharing and quantifying the benefits of data sharing. We use a case study on DGA-based botnet detection to evaluate how sharing cybersecurity data can improve detection sensitivity and allow the discovery of malicious activity with greater precision.

The relevant software is open-sourced and freely available at

This paper is joint work between Calvin Ardi and John Heidemann from USC/ISI, with additional support from collaborators and Colorado State University and Los Alamos National Laboratory.

Posted in Uncategorized | Tagged , , , , , , , , | Leave a comment

new conference paper “The Policy Potential of Measuring Internet Outages” at TPRC

We have published a new paper “The Policy Potential of Measuring Internet Outages” in TPRC46, the Research Conference on Communications, Information and Internet Policy, to be presented on September 21, 2018 at the American University, Washington College of Law.

Outages from Hurricane Irma after landfall in Florida on 2017-09-11, observed with Trinocular.

From the abstract of our paper:

Today it is possible to evaluate the reliability of the Internet. Prior approaches to measure network reliability required telecommunications providers reporting the status of their own networks, resulting in limits on the precision, timeliness, and availability of the results. Recent work in Internet measurement has shown that network outages can be observed with active measurements from a few sites, and from passive measurements of network telescopes (large, unused address space) or large network services such as content-delivery networks. We suggest that these kinds of *third-party* observations of network outages can provide data that is precise and timely. We discuss early results of Trinocular, an outage detection system using active probing developed at the University of Southern California. Trinocular has been operating continuously since November 2013, and we provide (at no charge) data covering about 4 million network blocks from around the world. This paper describes some results of Trinocular showing outages in a large U.S. Internet Service Provider, and those resulting from the 2017 Hurricane Irma in Florida. Our data shows the impact of the Broadband America policy for always-on networks, and we discuss how it might be used to address future policy questions and assist in disaster planning and recovery.

Data we describe in this paper is at, with visualizations at

This paper is joint work of John Heideman, Yuri Pradkin, and Guillermo Baltra from USC/ISI, with work carried out as part of LACANIC and DIVOICE projects with DHS S&T/CSD support.

Posted in Uncategorized | Tagged , , , , , , , , , , , , | Leave a comment

congratulations to Christopher Morales Ramos for his summer undergrad internship

We would to thank Christopher Morales Ramos for his summer internship at ANT, as part of the NSF-sponsored Research Experiences for Undergraduates (REU) Program at ISI in 2018:
Human Communication in a Connected World
. Christopher interned with us as part of his studies at the University of Puerto Rico where he is an undergraduate student in computer science.

Yuri Pradkin, Christopher Morales Ramos, and John Heidemann, with Christopher’s summer undergraduate research project poster.

Christopher’s project was improving the accuracy in estimating Round Trip Time (RTT) measurements from icmptrain our high-speed IPv4 prober, while minimizing the amount of traffic that was sent.  In addition to improving RTT estimates, his work can lead to better geolocation estimates.

His research at ISI was jointly advised by Yuri Pradkin and John Heidemann, as part of the ISI REU program directed by Jelena Mirkovic.

Posted in Uncategorized | Tagged , , , , , , , , | Leave a comment

new technical report “Detecting IoT Devices in the Internet (Extended)”

We have released a new technical report “Detecting IoT Devices in the Internet (Extended)” as ISI-TR-726.

ISP-Level Deployment for  26 IoT Device Types. From Figure 2 of [Guo18c].

From the abstract of our technical report:

Distributed Denial-of-Service (DDoS) attacks launched from compromised Internet-of-Things (IoT) devices have shown how vulnerable the Internet is to large-scale DDoS attacks. To understand the risks of these attacks requires learning about these IoT devices: where are they? how many are there? how are they changing? This paper describes three new methods to find IoT devices on the Internet: server IP addresses in traffic, server names in DNS queries, and manufacturer information in TLS certificates. Our primary methods (IP addresses and DNS names) use knowledge of servers run by the manufacturers of these devices. We have developed these approaches with 10 device models from 7 vendors. Our third method uses TLS certificates obtained by active scanning. We have applied our algorithms to a number of observations. Our IP-based algorithms see at least 35 IoT devices on a college campus, and 122 IoT devices in customers of a regional IXP. We apply our DNSbased algorithm to traffic from 5 root DNS servers from 2013 to 2018, finding huge growth (about 7×) in ISPlevel deployment of 26 device types. DNS also shows similar growth in IoT deployment in residential households from 2013 to 2017. Our certificate-based algorithm finds 254k IP cameras and network video recorders from 199 countries around the world.

We make operational traffic we captured from 10 IoT devices we own public at We also use operational traffic of 21 IoT devices shared by University of New South Wales at

This technical report is joint work of Hang Guo and  John Heidemann from USC/ISI.

Posted in Uncategorized | Tagged , , , , , , , , , , , , , | Leave a comment

release of the cryptopANT library for IP address anonymization

cryptopANT v1.0 (stable) has been released (available at

cryptopANT is a C library for IP address anonymization using crypto-PAn algorithm, originally defined by Georgia Tech. The library supports anonymization and de-anonymization (provided you possess a secret key) of IPv4, IPv6, and MAC addresses. The software release includes sample utilities that anonymize IP addresses in text, but we expect most use of the library will be as part of other programs. The Crypto-PAn anonymization scheme was developed by Xu, Fan, Ammar, and Moon at Georgia Tech and described in“Prefix-Preserving IP Address Anonymization”, Computer Networks, Volume 46, Issue 2, 7 October 2004, Pages 253-272, Elsevier. Our library is independent (and not binary compatible) of theirs.

Despite this being the first release as a library, the code has been in use for more than 10 years in other tools.  It had been part of our other software packages, such as dag_scrubber for years.  By popular request, we’re finally releasing it as a separate package.

The library is packaged with an example binary (scramble_ips) that can be used to anonymize text ips.

See also the crypto-PAn page at Georgia Tech here.

Posted in Software releases | Tagged , , , , , , , , , | Leave a comment
